35t Hydraulic Mobile Crane , XCT35 XCMG telescopic truck crane

Name: 35t Hydraulic Mobile Crane XCT35 XCMG telescopic truck crane
Brand: XCMG
Price: 1 USD

35t Hydraulic Mobile Crane , XCT35 XCMG telescopic truck crane Manufactures

Brand Name : XCMG

Model Number : XCT35

Certification : CE

Place of Origin : China

MOQ : 1pc

Price : negotiate

Payment Terms : 30% deposit, balance before shipment

Supply Ability : 10000pcs/year

Delivery Time : 30-50 days

Packaging Details : Ro-Ro 1400/1400 1390/（1200-1500）

Model : XCT35

Max.rated capacity : 35t

Engine model : SC9DF290.1Q4/D10.31-40

Total weight in travel : 35000kg

Contact Now

35t Hydraulic Mobile Crane , XCT35 XCMG telescopic truck crane

Feature

• The innovative jib system adopts embedded block, plug-in boom head and international advanced U section jib, which has excellent lifting performance and safe and reliable lifting work.
• The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
• Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
• The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.
• Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
• The humanity design makes the cab and control cab more spacious, and easy to operate.
• Six unique manufacturing technologies ensure the high quality.
• The working condition expands twice. Newly add 5t counterweight.

Technical Parameter

Dimension	Unit	XCT35
Overall length	mm	13065
Overall width	mm	2750
Overall height	mm	3540
Weight
Total weight in travel	kg	35000
Front axle load (axle 1, 2, 3)	kg
Rear axle load (axle 4, 5)	kg
Power
Engine model		SC9DF290.1Q4/D10.31-40
Engine rated power	kW/(r/min)	213/1900 228/1900
Engine rated torque	N.m/(r/min)	1400/1400 1390/ (1200-1500)
Travel
Max. travel speed	km/h	90
Min. turning diameter	m	22
Min. ground clearance	mm	260
Approach angle	°	19
Departure angle	°	12
Max. grade ability	%	42
Fuel consumption for 100km	L	32
Main performance
Max. rated total lifting capacity	t	35
Min. rated working radius	m	3
Base boom	m	10.1
Fully extended boom	m	41
Fully extended boom+ jib	m	56.8
Working speed
Boom luffing time	s	80
Boom full extension time	s	90
Max. swing speed	r/min	2.5

The specification is subject to change without notice.
